Description
6" FX6 35-9 – 400 V multistage submersible pump
The 6" FX6 35-9 submersible pump by IBO ITALY is a multistage, cast-iron pump manufactured in Italy, designed for drawing and pumping raw water in large water supply and industrial systems, as well as fire protection and irrigation systems, before treatment. Its compact diameter for this performance class allows installation in narrower wells than larger FX series models, while the option of horizontal operation further increases installation flexibility.
Who is it for?
- Multi-family buildings and larger water supply systems – the series’ wide range of power and capacity makes it possible to select a model for drawing and pumping raw water according to the scale of demand.
- Farms with high water demand – the higher-capacity models supply extensive irrigation systems, sprinklers, and drip lines.
- Industrial plants and fire protection systems – the cast-iron construction and wide power range are suitable for demanding continuous-operation systems.
- System installers and designers – the 153 mm pump diameter allows the model to be precisely matched to wells narrower than those intended for the FX8 and FX10 series.
Applications
The 6" FX6 pump is designed for drawing raw water from deep water intakes for multi-family homes, farms, irrigation systems, fire protection systems, industrial applications, and drainage. The pump is not a water treatment device; when using it for other purposes, we recommend ensuring appropriate water preparation.
The pump can operate in a vertical or horizontal position, with a maximum pumped-water temperature of 35°C. The 6" FX6 400 V submersible pump works with standard pressure tanks and pressure-control equipment selected for the scale of the system.
Features of the 6" FX6 pump
The 6" FX6 pump has a cast-iron construction (suction casing, diffuser, check valve – G25 cast iron) with stainless steel components – the shaft and coupling are made of AISI 420, bearing housings of AISI 316, and the filter screen, cable guard, and screws of AISI 304. The impeller is made of cast iron or bronze, depending on the model, while the seals are based on PU and NBR materials.
The maximum pump diameter, including the cable guard, is 153 mm, allowing installation in wells with a minimum internal diameter of 180 mm.
- Pump type: multistage, submersible, cast-iron construction
- Max. pump diameter with cable guard: 153 mm
- Minimum well diameter: 180 mm
- Power supply: 400 V (three-phase)
- Insulation class: F
- Protection rating: IP68
- Operating mode: continuous
- Operating position: vertical or horizontal
- Max. liquid temperature: 35°C
- Max. number of starts per hour: 30
- Rotational speed: 2850 rpm
- Materials: casing, diffuser, check valve – G25 cast iron, shaft and coupling – AISI 420 stainless steel, bearing housings – AISI 316, cable guard and filter screen – AISI 304
IBO ITALY – 36-month (3-year) manufacturer’s warranty. Warranty and post-warranty service is provided by Dambat.
Dambat – a trusted manufacturer of pumps and water engineering equipment with quality certifications.
Frequently asked questions (FAQ) – 6" FX6 submersible pump
What type of well is the 6" FX6 pump suitable for?
The 6" FX6 pump requires a well with a minimum internal diameter of 180 mm, while the maximum diameter of the pump itself, including the cable guard, is 153 mm.
How does the 6" FX6 series differ from the FX8 and FX10 series?
All three series have an identical cast-iron construction, but they differ in diameter and the resulting capacity – the 6" FX6 has the smallest diameter and fits narrower wells, while the FX8 and FX10 are intended for wider boreholes and larger systems.
What distinguishes the 6" FX6 pump?
The pump has a cast-iron construction with AISI 304/316/420 stainless steel components, ensuring durability during continuous operation. It can operate in both vertical and horizontal positions, and the built-in check valve limits water backflow from the system after the pump is switched off.
How do I choose the right 6" FX6 pump model for my needs?
The choice of model depends on the well depth and the amount of water needed simultaneously – the series includes a wide range of variants with different power ratings, heads, and capacities. If in doubt, we encourage you to contact the technical department.
Where can I buy the 6" FX6 submersible pump?
Dambat does not sell directly. The 6" FX6 pump is available from trade partners, installation wholesalers, and authorized online distributors.
What warranty terms apply to the 6" FX6 pump?
IBO ITALY – 36-month (3-year) manufacturer’s warranty. Warranty and post-warranty service is provided by Dambat.
- Power: 11.0 kW,
- Power supply: 300–400 V,
- Frequency: 50 Hz,
- Current draw: 26.0 A,
- Motor speed: 2850 rpm,
- Dimensions: 151/1238 mm
- Weight: 65.0 kg,
