4 "Spinox 3-29 (2.2kW, 400V) deep pump with a water engine IPRO

iQ PRIndex: KAT01372 EAN: 5903887237260
No review

Description

Multi -stage deep pumps with a diameter of 98 mm, entirely made of stainless steel, are intended for installation in wells with a minimum internal diameter of 115 mm. The pump is used to supply single and multi -family houses, farms, as well as to supply ironation systems (sprinklers, drop lines) and drainage lines.

CHARACTERISTICS

  • Pumps entirely made of stainless steel,
  • Water engine IPRO,
  • Increased wear resistance,
  • Built -in check valve,
  • 1.5 m supplying cable,
  • The highest quality materials,
  • Warranty and post -warranty service,
  • Warranty 36 months.
  • Diameter: 4”,
  • Lifting: 184.0 M,
  • Efficiency: 75.0 l/min.,
  • Power: 2.2 kw,
  • Power supply: ,
  • Frequency: 50 Hz,
  • Current: 6.3 AND,
  • Engine speed: 2850 rpm,
  • Insulation class: F,
  • Working mode: continuous,
  • Degree of protection: IP68,
  • Connection [mm/incly]: 1¼,
  • Work position: Vertical,
  • Liquid temperature: 35° C,
  • Max. Number of starts at 1H: ,
  • Depth of immersion: 150 M,
  • Power cable length: 1.5 M,
  • Dimension diamond/height: 97/1385 mm,
  • Libra: 34.4 kg,

----------

Material
• suction/pressing: AISI 304 stainless steel,
• housing: AISI 304 stainless steel,
• shaft and rotor: Aisi 304 stainless steel,
• VERTIC: AISI 304 stainless steel,
• diffuser: AISI 304 stainless steel,
• Mechanical seal: ceramics/sic/nbr,
• water -cooled engine.
